Used Glycerin Plant MAZZONI

CONCENTRATION AND DISTILLATION PLANT for GLYCERIN "MAZZONI" SOLD

Capacity: 500 Kg/h of concentrate glycerin and 50 kg/h of pure glycerin.

CONDITIONS: EXCELLENT

MANUFACTURER: MAZZONI

LOCATED IN: AMERICA

CONCENTRATION PLANT "MAZZONI CGSL 500" :
1-) Air compressor (Not included)
1-) Crude Glycerin Tank

2,5-) Boiler to treat glycerin solutions (there are tanks) Not included

3-) Pump to feed first filter

4-7-) Filter press

6-) Pump to feed second filter

8-) Tank of refined glycerin

9-) Pump for refined glycerin

10-) Tank to feed evaporator

11-12-) Evaporator first stage

13-) Salt separator

14-) Trawl Separator

15-16-) Evaporator second stage

17-) Salt separator

18-) Trawl separator

19-) Barometric Condenser

20-) Vacuum Pump

21-) Steam pipes

22-) Steam group

23-) Condense extraction pump

24-) Tank semi concentrated glycerin (Not included)

25-) Tank concentrated glycerin (Not included)

DISTILLATION PLANT "MAZZONI DG 50" :

2-) Re-heater of direct steam

3-) Distillation Boiler

4-) Trawl separator for glycerin vapors

5-) First condenser for glycerin vapors

6-) Second condenser for glycerin vapors

7-) Cooler condenser for vapors of glycerin

8-) Barrel for high concentration glycerin

9-) Barrel for high concentration glycerin

10-) Barrel for diluted glycerin

11-) Auxiliary Cooler for distillated water to cool glycerin condenser

12-) Vacuum steam ejector

13-) Mixer condenser

14-) Extraction pump for distillated high concentration glycerin

15-) Extraction pump for distillated low concentration glycerin

16-) Recirculation pump for distillated water

17-) Vacuum pump

18-) Glycerin Clarification boiler

19-) Press filter

20-) Feed Pump for press filter
